Type 2 to 3 pin Charging Cable 10A For EV Charging With A 13A Socket

170.00 € – 190.00 € vat included

Type 2 to Schuko charger (Notladekabel) that will charge your e-auto at 16A. This charger will provide up to 3,7kW when using a 16A Schuko socket and is suitable for emergency charging your electric vehicle at home or anywhere there is a Type F (Schuko) socket. This charger has a Type A RCD. For using a 16A socket to regularly charge an EV, or if the Schuko socket is not protected by a Type B RCD, we recommend our adjustable current Schuko charger, which has an integrated sensor that provides DC current detection equivalent to a Type B RCD and an optional temperature sensor in the plug. This charger is also available with lengths of 7.5 metres, 10 metres and 15 metres.

Please note that the unit box of this 16A fixed amp charger is IP65. This means that the unit box should be sheltered during heavy rain or snow. If you are placing the control box outdoors, we recommend the IP67 waterproof option that is available for the adjustable current Schuko charger.

Please consult with an electrician to ensure that the socket and electrical circuit used for charging your vehicle is suitable for charging a BEV / PHEV. Read below for important details about this Schuko charging cable.

Bag included for cables up to 15M.
Free shipping available.
Extended 3 year warranty. See below.
Please Read Before You Buy

Our Schuko charging cables are normally returned for one of the reasons below. Reading this information may help you to avoid having to return the charger. Please also read all the information on this page as it contains important information about this Schuko charger.

Ensure compatibility between the charging cable and your vehicle. The images on this page provide a visual guide to the connector pins, allowing you to match the cable plug to your vehicle socket. You can also use our EV Cable Finder to locate your vehicle and explore the charging cables available for your vehicle.

Is the cable long enough? Measure the distance from your Schuko socket to your Type 2 vehicle socket, typically where your vehicle is parked, and add half a meter to prevent overstretching the cable.

Cable Care & Warranty

To ensure the proper care of your charger, be sure to follow the safety instructions outlined in the user booklet provided with your charging cable. These Schuko chargers have a 24 months repair warranty for any defects that are caused by a manufacturing fault. Following the instructions and safety information for using the Type 2 to Schuko charger will help to ensure trouble-free use. In case you do not receive the user booklet, please notify us. Additionally, check our EV Cable Care Guide for valuable tips on safely using your mobile charger and how to avoid common issues that may lead to the charger malfunctioning.

Click the options below to view the price and availability. Click “Clear” to reset the options. Prices include VAT. Please read all of the product information below before purchasing.

Next Working Day shipping for goods showing as In Stock. Order before 1pm. Excludes weekends and bank holidays. For goods displayed as Preorder, the expected shipping time will be displayed above.

  • UK company. Established since 2018.
  • Major payment cards accepted.
  • Pay by Klarna. Terms apply.
Secure Checkout

Mastercard, visa, klarna, american express, paypal, apple pay, google pay, microsoft pay accepted

Type 2 To Schuko Charging Cable For Plugging Into A 16A Household Socket. Charges All Type 2 Socket Electric Vehicles

This Type 2 to Schuko charging cable can charge an EV at 16A, which equates to around 3,7kW or 15 to 25 kM of charge per hour.

Plug this Mode 2 charger into a 16A Type F Schuko socket to charge your EV at 16A. This mobile charger is recommended for emergency charging. For example, if you are visiting an area without any charging facilities nearby.

If you are using a 16A Schuko socket to charge your EV regularly and for longer periods, we recommend our adjustable current mobile charger as this will allow you to charge the vehicle at the lower recommended current of 10A. Charging your electric vehicle at 10A significantly reduces the risk of the socket overheating.

Being able to reduce the charging current reduces the heat stress on a mains socket. This is important if a 16A socket lacks a dedicated circuit connection. Or where the circuit and socket haven’t been certified for charging an electric vehicle by a qualified electrician. Variable charging will also allow the charger and/or the vehicle to reduce the current if overheating is detected.

The variable current charger includes AC and DC current protection and has a timer that allows delayed charging from 1 to 10 hours. There is also an option for a waterproof enclosure and a temperature sensor inside the Schuko plug to help prevent the Schuko socket overheating.

Photo of Schuko mobile charger that connects to a 16a household socket
Picture showing a Type 2 EV socket and a CCS socket
9 hole Type 2 / CCS socket and a 7 hole Type 2 socket

Is This Mobile Charger Suitable For My EV / PHEV?

Choosing The Right Mobile Charger

To use this Schuko charger, your vehicle must have a Type 2 socket. Refer to the photo of a Type 2 socket on this page and match it to your vehicle.

If you are still not sure, click the button below to find your BEV/PHEV. This will enable you to verify if your vehicle is equipped with a Type 2 socket. Additionally, please review the information at the top of this page under “Please Read Before You Buy”. This information will help you to avoid the most common reasons for returning a Schuko charging cable.

Use A Suitable Socket

Charging an electric vehicle for long periods with a Schuko socket may cause thermal damage to the socket. For example, the socket might overheat if the socket is damaged, if there is faulty wiring, or if the electrical circuit is overloaded. It is rare, but it does happen.

For this reason, we strongly recommend that an electrician inspects the Schuko socket to certify its suitability for charging your vehicle.

We understand that, at times, charging your EV with a socket certified by an electrician may not be feasible. In such instances, we recommend the variable amp charger as it provides additional protection for the 3-pin socket. It is also a good idea to ensure that both the plug and socket are not becoming excessively hot during charging.

Do not use an extension lead or adapter with this Type 2 to 3 pin charger. Plug the charger directly into the socket. Ensure that water does not come into contact with the 3-pin plug or the Type 2 plug, and keep the charger dry when not in use. Before using this charger, be sure to read the user booklet included with the charger.

How Waterproof Is This Mobile Charging Cable?

This charger consists of four main components: the Schuko plug, the cable, the control box (unit), and the Type 2 plug.

Schuko Plug: The plug should be safe from water if you are plugging it into an indoor socket. If you are using an outdoor socket, the Schuko plug needs to be protected and you should therefore use a weatherproof socket.

Cable: The cable is waterproof as long as there are no cuts or tears in the cable sheath.

Control Box: The standard control box is IP65-rated. This rating means that the control box can withstand light rain. If you are placing the control box outside, you can select the option to upgrade to the IP67-rated control box. This rating means that the control box is fully weatherproof.

Type 2 Plug: The Type 2 plug is built with an outer shell that is designed to withstand rain and snow when connected to the vehicle socket. The vehicle socket is also designed to be watertight and should therefore provide protection from water ingress when the Type 2 plug is connected.

A common way for water to enter the Type 2 plug is when the plug cap is replaced after charging. The plug cap must always be replaced after charging your vehicle, but do ensure that the inside of the plug cap is dry. Avoid leaving the plug lying around outside, do not drag or drop the Type 2 plug on the ground and store the charger in a dry place when not in use.

Features

  • IP65 protection for the control box.
  • Certification: CE.
  • 30mA AC Type A RCD.
  • Built in fault detection: Earth leakage, over voltage / under voltage, over current and surge protection.
  • PCB Overheating protection: The charging current will automatically reduce if the circuit board in the device box exceeds 75 degrees.

Choice Of Cable Bags

We provide a free canvas cable bag (suitable for cables up to 15M) to store this charger when not in use. You can also upgrade the bag to a cable case made from EVA material for enhanced waterproofing and impact protection. The EVA case has an elasticated strap in the bottom compartment and elasticated mesh pocket in the top. So it allows convenient storage of two cables. The EVA case can therefore carry 2 cables if each cable does not exceed 10 metres length (20M total length).

Type 2 To Schuko Charging Cable Technical Data

Charging cable typeMode 2. Schuko plug to Type 2 (IEC 62196-2) connector
Lengths available5 Metres. 7.5M, 10M and 15M lengths available with the adjustable current 3-pin charger
Rated current16A
CertificationCE, UKCA, TUV tested
Cable from control box to power outletTPE 3×2.5+2×0.75mm. Length including plug: 70cm
Cable to Type 2 vehicle plugTPU 3×2.5+1×0.75mm
Control box dimensions210mm (H) x 85mm (W) x 50mm (D)
IP gradeControl box: IP65. Plugs when connected to sockets: IP55
Operating voltage220V-240V AC
Leakage protectionAC leakage 30mA
Working temperature-30°C to 50°C
Flame retardantUL94 V-0
Insulation resistance10MΩ

This Charger is Compatible with The Following Type 2 Socket Vehicles

If your vehicle is not in this list then please contact us to confirm that your vehicle is compatible.

Abarth

Abarth 500e

Aiways

Aiways U5, Aiways U6

Alpine

Alpine A290, Alpine A390

Alfa Romeo

Alfa Romeo Giulia, Alfa Romeo Junior Elettrica, Alfa Romeo Tonale

Audi

Audi A3 PHEV, Audi A5 PHEV, Audi A6 e-tron, Audi A6 PHEV, Audi A7 PHEV, Audi A8 PHEV, Audi Q3 PHEV, Audi Q5 PHEV, Audi Q7 PHEV, Audi Q8 PHEV, Audi e-tron Sportback, Audi e-tron GT, Audi Q3 e-tron, Audi Q4 e-tron, Audi Q6 e-tron, Audi Q7 e-tron, Audi Q8 e-tron, Audi RS e-tron, Audi SQ8 e-tron, Audi S6 e-tron, Audi SQ6 e-tron

Bentley

Bentley Continental, Bentley Bentaga, Bentley Flying Spur

BMW

BMW 225xe, BMW 320e, BMW 330e, BMW 520e, BMW 530e, BMW 745e, BMW i3, BMW i4, BMW i5, BMW i7, BMW i8, BMW iX, BMW iX1, BMW iX2, BMW iX3, BMW X1 xDrive25e, BMW X2 xDrive25e, BMW X3 xDrive25e, BMW X5 xDrive25e, BMW XM

BYD

BYD Atto 3, BYD Dolphin, BYD Dolphin Surf, BYD Han, BYD Seagull, BYD Seal, BYD Sealion 7, BYD Tang

Chevrolet

Spark

Citroen

Citroen Berlingo (manufactured from 2021), Citroen C5 Aircross, Citroen C5 X, Citroen Dispatch, Citroen e-C3, Citroen e-C4, Citroen Jumpy, Citroen Spacetourer

Cupra

Cupra Born, Cupra Formentor, Cupra Leon, Cupra Raval, Cupra Tavascan, Cupra Terramar, Cupra Urban Rebel

Dacia

Dacia Spring

Dongfeng

Dongfeng Box

DS

DS 3 Crossback E-Tense, DS 4 E-Tense, DS 7 Crossback E-Tense, DS 9 E-Tense

Elaris

Elaris BEO

Fiat

Fiat 500e (manufactured from 2021), Fiat 600e, Fiat E-Ulysse, Fiat Grande Panda

Fisker

Fisker Ocean

Ford

Ford Capri, Ford F-150 Lightning, Ford Kuga PHEV, Ford Mustang MACH-E, Ford Puma, Ford Transit, Ford Tourneo

Genesis

Genesis GV60, Genesis GV70, Genesis GV80

GWM / ORA

GWM Ora 03, ORA Funky Cat

Honda

Honda CR-V e:PHEV, Honda e, Honda e:Ny1

Hyundai

Hyundai INSTER, Hyundai Ioniq, Hyundai Ioniq 5, Hyundai Ioniq 6, Hyundai Ioniq 7, Hyundai Kona, Hyundai Santa Fe Hybrid, Hyundai Tucson Hybrid

Jaguar

Jaguar E-Pace, Jaguar F-Pace, Jaguar I-Pace

Jeep

Jeep Avenger, Jeep Compass, Jeep Grand Cherokee, Jeep Recon, Jeep Renegade, Jeep Wrangler

Kia

Kia EV3, Kia EV6, Kia EV9, Kia Ceed, Kia Optima, Kia eNiro, Kia Niro, Kia Sorento, Kia Soul (manufactured from 2020), Kia Sportage, Kia Xceed

Land Rover

Land Rover Defender, Land Rover Discovery, All Range Rover Models

Lancia

Lancia Ypsilon

Leapmotor

Leapmotor C10, Leapmotor T03

LEVC

LEVC TX, LEVC TX5, LEVC LCV, LEVC VN5

Lexus

Lexus NX, Lexus RX, Lexus RZ, Lexus UX

Lucid

Lucid Air

Lync & Co

Lync & Co 02

Mahindra

Mahindra e20, Mahindra eVerito

MAN

MAN eTGE

Maxus

Maxus eDeliver 3, Maxus eDeliver 7, Maxus eDeliver 9, Maxus MIFA 9, Maxus T90EV

Mazda

Mazda MX-30, Mazda CX-60, Mazda CX-90

Mercedes

Mercedes A 250e, Mercedes B Class E-Cell, Mercedes CLA, Mercedes C 300e, Mercedes C 300de, Mercedes C 350de, Mercedes C 350e, Mercedes E 300de, Mercedes E 300e, Mercedes E 350de, Mercedes E 350e, Mercedes EQA, Mercedes EQB, Mercedes EQC, Mercedes EQE, Mercedes EQS, Mercedes EQV, Mercedes G 580, Mercedes GLA, Mercedes GLC, Mercedes GLE, Mercedes GLS, Mercedes S 450e, Mercedes S 500, Mercedes S 560, Mercedes S580e, Mercedes SLS 500, Mercedes Sprinter Van, Mercedes Vito Van

MG

MG4, MG5, MG HS, MG Cyberster G, MG Marvel R, MG S5, MG ZS

Mini

Mini Aceman, Mini Countryman, Mini Countryman Electric, Mini Cooper, Mini Electric

Mitsubishi

Mitsubishi Eclipse

Nio

Nio ET5, Nio EL6, Nio EL7, Nio ET7

Nissan

Nissan Ariya, Nissan Leaf (Leaf manufactured from 2018)

Omada

Omada E5, Omada 7, Omada 9

Opel

Opel Ampera e (manufactured from 2019), Opel Astra e, Opel Astra Hybrid, Opel Combo e, Opel Corsa e, Opel Frontera, Opel Grandland, Opel Grandland X, Opel Movano e, Opel Mokka e, Opel Vivaro e, Opel Zafira e

Ora

Ora Funky Cat

Peugeot

Peugeot 308, Peugeot 3008, Peugeot 408, Peugeot 508, Peugeot e-208, Peugeot e-2008, Peugeot e-3008, Peugeot e-5008, Peugeot e-Expert, Peugeot e-Rifter, Peugeot e-Traveller, Peugeot Partner (manufactured from 2022)

Polestar

Polestar 1, Polestar 2, Polestar 3, Polestar 4

Porsche

Porsche 918 Spyder, Porsche Panamera Hybrid, Porsche Macan, Porsche Panamera Hybrid, Porsche Taycan

Range Rover / Land Rover

Range Rover Electric, Range Rover Evoque, Range Rover P300, Range Rover Sport, Range Rover Velar, All Land Rover models

Renault

Renault 5 E-tech, Renault Captur, Renault Clio E-tech, Renault Kangoo (Type 2 Socket), Renault Kangoo ZE (Type 2 Socket), Renault Master van, Renault Megane, Renault R4, Renault R5, Renault Scenic, Renault Zoe (All models manufactured from 2012)

Seat

Seat el-Born, Seat Leon, Seat Minimo, Seat Mii electric, Seat Tarraco

Skoda

Skoda Citigo, Skoda Elroq, Skoda Enyaq, Skoda Kodiaq, Skoda Octavia, Skoda Superb, Skoda Vision

Smart

Smart #1, Smart #3, Smart Cabrio, Smart forfour, Smart fortwo

SsangYong

SsangYong Korando e-Motion

Subaru

Subaru Solterra

Tesla

Tesla Model 3, Tesla Model S, Tesla Model X, Tesla Model Y

Toyota

Toyota bZ4X, Toyota C-HR PHEV, Toyota Prius (Toyota Prius manufactured from 2017), Toyota Proace, Toyota RAV4

Vinfast

Vinfast VF 6, Vinfast VF 8

Volvo

Volvo C30, Volvo C40, Volvo EC40, Volvo EX30, Volvo EX40, Volvo EX90, Volvo S60, Volvo S90, Volvo V60, Volvo V90, Volvo XC40, Volvo XC40 recharge, Volvo XC60, Volvo XC60 recharge, Volvo XC90, Volvo XC90 recharge

VW

VW Arteon eHybrid, VW e-Golf, VW e-Transporter, VW e-Up, VW Golf eHybrid, VW Golf GTE, VW ID2, VW ID3, VW ID4, VW ID5, VW ID7, VW ID Buzz, VW Multivan, VW Passat eHybrid, VW Passat GTE, VW Tiguan eHybrid, VW Tayron, VW Touareg

Xpeng

Xpeng G6, Xpeng G7, Xpeng P9

Zeekr

Zeekr 001, Zeekr X
